TP-Link EC220-G5 AC1200 Wireless Dual Band Wi-Fi Gigabit Router

The TP-Link EC220-G5 is a dual-band gigabit wireless router designed for fast connectivity, strong coverage, and advanced security for home and office use.

 Wireless Performance

• Data Rate: AC1350

  • 5 GHz: Up to 568 Mbps (802.11ax, HE160)

  • 2.4 GHz: Up to 300 Mbps (802.11ax)

• Frequency: 2.4 GHz & 5 GHz

• WiFi Capacity: Medium, Dual-Band with MU-MIMO support

• Beamforming: Focuses signal toward connected devices for better coverage

• Wireless Modes: Router Mode, Access Point Mode

• Wireless Functions: Enable/Disable WiFi, WDS Bridge, WMM, Wireless Schedule, Wireless Statistics

 Hardware & Ports

• Antennas: 4 External Antennas

• Ethernet Ports:

  • 1× Gigabit WAN Port

  • 4× Gigabit LAN Ports

• Buttons:

  • Wi-Fi On/Off

  • Power On/Off

  • WPS/Reset

• Processor: Qualcomm CPU

• Power Interface: 12V / 1.0A

 Security & Protection

• Encryption: WPA / WPA2 / WPA3 / WPA-WPA2 Enterprise (802.1x)

• Security Features:

  • SPI Firewall

  • Access Control

  • IP & MAC Binding

  • Application Layer Gateway

• VPN Server Support: OpenVPN, PPTP

• Guest Network:

  • 1× 2.4 GHz Guest Network

  • 1× 5 GHz Guest Network

• EasyMesh Compatible with 802.11 k/v support

 WiFi Coverage & Transmission

• Suitable for 3-bedroom houses

• Multiple antennas create a signal-boosting array

• Transmit Power (CE):

  • <20 dBm (2.4 GHz)

  • <23 dBm (5 GHz)

• FCC: <30 dBm (2.4 GHz & 5 GHz)

 Environmental & Physical Details

• Dimensions: 230 × 144 × 37 mm

• Operating Temperature: 0℃–40℃

• Storage Temperature: -40℃–60℃

• Operating Humidity: 10%–90% (non-condensing)

• Certifications: CE, RoHS

 Package Contents

• EC220-G5 Wireless Dual Band Router

• Power Adapter

• RJ45 Ethernet Cable

• Quick Installation Guide

 System Requirements

• Compatible with Windows, macOS, NetWare, UNIX, Linux

• Supported Browsers: IE 11+, Firefox 12+, Chrome 20+, Safari 4+

• Requires cable/DSL modem (if needed)

• Active ISP subscription required

 Warranty

• 1 Year Warranty

The TP-Link EC220-G5 offers reliable dual-band performance, strong security features, and wide coverage—making it a practical solution for modern home networking.
